WordPress + Redis Object Cache: Optimized Configs for Localhost, Docker, and ElastiCache

Redis is fantastic for WordPress—but its defaults are meant for a datastore, not a high-churn object cache. This guide shows you the exact Redis settings for localhost, Docker, and Amazon ElastiCache so you get a memory-bounded, low-latency cache with smart eviction and stable performance.

Using Redis as a cache for WordPress (via the Redis Object Cache plugin) is a great way to cut database load and speed up page generation. Two things determine how well it works: where Redis runs (same host, Docker, or a managed service like Amazon ElastiCache for Redis) and the fact that Redis’s default configuration is not tuned for WordPress caching.

Out of the box, Redis ships with disk persistence enabled, no memory ceiling (maxmemory 0), and a noeviction policy—sensible for a datastore, but sub‑optimal for a high‑churn object cache. For WordPress you want an ephemeral, memory‑bounded cache with an allkeys-* eviction policy, active defragmentation, and lazy frees enabled.

Why the defaults aren’t ideal for WordPress

maxmemory is unset → the OS may OOM‑kill Redis under pressure.

maxmemory-policy noeviction → writes can fail at high memory instead of evicting cold keys.

Persistence is enabled → unnecessary disk I/O and longer restarts for a cache‑only role.

Active defragmentation is off → RSS can bloat long after traffic subsides.

This guide gives production‑ready settings for each deployment scenario, with copy‑pasteable snippets, and a short checklist to verify things are working.

TL;DR (Quick Recipe)

Treat Redis as ephemeral cache (no disk durability).
Set a memory ceiling and an eviction policy: maxmemory + allkeys-lfu (or allkeys-lru).
Turn on active defragmentation and lazyfree to stabilize memory.
Prefer phpredis client with persistent connections from PHP-FPM.
Give objects a sane TTL (1–24h) and a unique key prefix per site.
Monitor: redis-cli --stat, INFO, SLOWLOG, latency doctor.

Baseline: Redis as a WordPress Cache (applies everywhere)

Use these baseline settings whether Redis is local, containerized, or managed:

Key Redis settings

# Treat as cache only: disable on-disk persistence
save ""
appendonly no

# Memory ceiling & eviction (tune size to your host/service)
maxmemory 1gb                 # adjust to your environment
maxmemory-policy allkeys-lfu  # or allkeys-lru
maxmemory-samples 7           # better sampling for LFU/LRU

# Memory stability
activedefrag yes
active-defrag-cycle-min 10
active-defrag-cycle-max 75

# Free deletes/expirations off the main thread
lazyfree-lazy-eviction yes
lazyfree-lazy-expire yes
lazyfree-lazy-server-del yes

# Connection hygiene
tcp-keepalive 60
timeout 0                     # keep pooled connections alive

# Observability
latency-monitor-threshold 100   # collect latency samples (µs)
loglevel notice

# Treat as cache only: disable on-disk persistence

save ""

appendonly no

# Memory ceiling & eviction (tune size to your host/service)

maxmemory 1gb # adjust to your environment

maxmemory-policy allkeys-lfu # or allkeys-lru

maxmemory-samples 7 # better sampling for LFU/LRU

# Memory stability

activedefrag yes

active-defrag-cycle-min 10

active-defrag-cycle-max 75

# Free deletes/expirations off the main thread

lazyfree-lazy-eviction yes

lazyfree-lazy-expire yes

lazyfree-lazy-server-del yes

# Connection hygiene

tcp-keepalive 60

timeout 0 # keep pooled connections alive

# Observability

latency-monitor-threshold 100 # collect latency samples (µs)

loglevel notice

Choose maxmemory: On a dedicated Redis host, start with ~50–70% of RAM. On a shared web server, start smaller (e.g., 512MB–1GB) and watch evictions and OS memory pressure.

WordPress plugin (typical) wp-config.php additions

// Prefer the phpredis PHP extension
define('WP_REDIS_CLIENT', 'phpredis');

// Connection (examples — pick the one that matches your setup below)
// define('WP_REDIS_HOST', '127.0.0.1');
// define('WP_REDIS_PORT', 6379);

// If using TLS (e.g., ElastiCache with in-transit encryption):
// define('WP_REDIS_SCHEME', 'tls');

// Performance knobs
define('WP_REDIS_MAXTTL', 86400);      // 24h; adjust to your cache strategy
define('WP_REDIS_PREFIX', 'wp_');      // or per-site slug (see below)
define('WP_CACHE_KEY_SALT', 'example.com:'); // uniqueness across sites

// Connection reuse (if supported by your plugin version)
define('WP_REDIS_PERSISTENT', true);

// Prefer the phpredis PHP extension

define('WP_REDIS_CLIENT', 'phpredis');

// Connection (examples — pick the one that matches your setup below)

// define('WP_REDIS_HOST', '127.0.0.1');

// define('WP_REDIS_PORT', 6379);

// If using TLS (e.g., ElastiCache with in-transit encryption):

// define('WP_REDIS_SCHEME', 'tls');

// Performance knobs

define('WP_REDIS_MAXTTL', 86400); // 24h; adjust to your cache strategy

define('WP_REDIS_PREFIX', 'wp_'); // or per-site slug (see below)

define('WP_CACHE_KEY_SALT', 'example.com:'); // uniqueness across sites

// Connection reuse (if supported by your plugin version)

define('WP_REDIS_PERSISTENT', true);

Prefixing: Use a unique WP_CACHE_KEY_SALT (or WP_REDIS_PREFIX) per site (e.g., domain name) to avoid key collisions in shared Redis.

Scenario A — Redis on the Web Server (localhost)

Best for: single server or small clusters where latency should be minimal and ops are simple.

Advantages

Lowest latency (UNIX socket possible)
Easiest to operate

How to configure

Install Redis from your distro or a trusted package (prefer 7.x).
Drop the baseline redis.conf above into /etc/redis/redis.conf.
(Optional) Use a UNIX socket for lower overhead:

unixsocket /var/run/redis/redis.sock unixsocketperm 770 # Add your web/PHP-FPM user to the redis group

1
2
3
4

unixsocket /var/run/redis/redis.sock
unixsocketperm 770
# Add your web/PHP-FPM user to the redis group
Set maxmemory to a safe ceiling for your host.
Restart Redis and point WordPress to the socket or 127.0.0.1:6379.

WordPress config example (UNIX socket)

// If your plugin supports sockets, you can use a path like this:
// define('WP_REDIS_SOCKET', '/var/run/redis/redis.sock');
// Otherwise, stick with 127.0.0.1:6379.

// If your plugin supports sockets, you can use a path like this:

// define('WP_REDIS_SOCKET', '/var/run/redis/redis.sock');

// Otherwise, stick with 127.0.0.1:6379.

Verification

redis-cli -s /var/run/redis/redis.sock INFO memory (or -h 127.0.0.1)
Ensure evicted_keys rises slowly once used_memory nears maxmemory.
Watch mem_fragmentation_ratio and run MEMORY PURGE during a maintenance window if fragmentation climbs.

Scenario B — Redis in Docker

Best for: containerized stacks (Docker Compose, Swarm, or K8s) that isolate services.

Advantages

Easy, reproducible deployments
Clean separation between app and cache

docker-compose.yml (example)

version: '3.9'
services:
  redis:
    image: redis:7-alpine
    command: ["redis-server", "/usr/local/etc/redis/redis.conf"]
    volumes:
      - ./redis.conf:/usr/local/etc/redis/redis.conf:ro
    # No /data volume needed for cache-only
    ports:
      - "6379:6379" # expose only if needed outside the compose network
    healthcheck:
      test: ["CMD", "redis-cli", "PING"]
      interval: 10s
      timeout: 2s
      retries: 5

  wordpress:
    image: wordpress:php8.2-fpm
    environment:
      # ... your DB env vars ...
    depends_on:
      - redis
    # Connect via service DNS name "redis" on port 6379

version: '3.9'

services:

redis:

image: redis:7-alpine

command: ["redis-server", "/usr/local/etc/redis/redis.conf"]

volumes:

- ./redis.conf:/usr/local/etc/redis/redis.conf:ro

# No /data volume needed for cache-only

ports:

- "6379:6379" # expose only if needed outside the compose network

healthcheck:

test: ["CMD", "redis-cli", "PING"]

interval: 10s

timeout: 2s

retries: 5

wordpress:

image: wordpress:php8.2-fpm

environment:

# ... your DB env vars ...

depends_on:

- redis

# Connect via service DNS name "redis" on port 6379

redis.conf

Use the baseline from above.
Set maxmemory appropriate to the container memory limit. If using Docker memory limits, ensure the container has enough headroom (Redis will not see host limits automatically).

WordPress config example

define('WP_REDIS_HOST', 'redis');  // service name from compose
define('WP_REDIS_PORT', 6379);

define('WP_REDIS_HOST', 'redis'); // service name from compose

define('WP_REDIS_PORT', 6379);

Kubernetes notes

Use a Deployment or StatefulSet for Redis with a ConfigMap for redis.conf.
Add resources requests/limits and a readinessProbe using redis-cli PING.

Scenario C — Amazon ElastiCache for Redis

Best for: high availability, managed patching, and easy scaling in AWS.

Topology

Replication group with 1 primary + ≥1 replica; enable Multi‑AZ and automatic failover.
Start with cluster mode disabled (single endpoint) unless you specifically need sharding, which requires cluster‑aware clients.

Parameters (Parameter Group)

Disable persistence: set save to empty ("").
Eviction: maxmemory-policy = allkeys-lfu (or allkeys-lru).
Memory stability: activedefrag = yes; enable lazyfree-* options if available.
Connection hygiene: tcp-keepalive = 60.
(ElastiCache sets maxmemory automatically per node size; choose instance classes with enough headroom.)

Security

Place Redis in a private subnet; restrict Security Groups to your app servers.
If in‑transit encryption is enabled, connect over TLS.

WordPress config examples

// Plain (no TLS)
define('WP_REDIS_HOST', 'my-redis.xxxxxx.ng.0001.use1.cache.amazonaws.com');

// TLS (if enabled)
define('WP_REDIS_SCHEME', 'tls');
define('WP_REDIS_HOST', 'my-redis.xxxxxx.use1.cache.amazonaws.com');
// phpredis also supports "tls://host" style in WP_REDIS_HOST for some setups

// Auth token (if configured)
// define('WP_REDIS_PASSWORD', '...');

// Timeouts (network has more jitter than localhost)
define('WP_REDIS_TIMEOUT', 1.0);
define('WP_REDIS_READ_TIMEOUT', 1.0);

// Plain (no TLS)

define('WP_REDIS_HOST', 'my-redis.xxxxxx.ng.0001.use1.cache.amazonaws.com');

// TLS (if enabled)

define('WP_REDIS_SCHEME', 'tls');

define('WP_REDIS_HOST', 'my-redis.xxxxxx.use1.cache.amazonaws.com');

// phpredis also supports "tls://host" style in WP_REDIS_HOST for some setups

// Auth token (if configured)

// define('WP_REDIS_PASSWORD', '...');

// Timeouts (network has more jitter than localhost)

define('WP_REDIS_TIMEOUT', 1.0);

define('WP_REDIS_READ_TIMEOUT', 1.0);

Failover

Point WordPress at the primary endpoint of the replication group. On failover, ElastiCache promotes a replica; the primary endpoint DNS updates automatically.

Verification

From an EC2 instance in the same VPC:

redis-cli -h <primary-endpoint> -p 6379 --tls # add -a <token> if auth is on INFO memory INFO stats

1
2
3
4

redis-cli -h <primary-endpoint> -p 6379 --tls # add -a <token> if auth is on
INFO memory
INFO stats
Watch evicted_keys, hit/miss rates, and latency.

Monitoring & Tuning Checklist

Hit ratio: keyspace_hits vs keyspace_misses → adjust TTLs and cache coverage.
Evictions: evicted_keys → steady non‑zero is normal at capacity; spikes suggest undersized maxmemory or too‑short TTLs.
Fragmentation: mem_fragmentation_ratio → >2 for long periods? Enable activedefrag and occasionally run MEMORY PURGE during low traffic.
Latency: latency doctor, SLOWLOG GET 128 → track slow commands and outliers.
Connections: Prefer persistent connections; avoid connection churn.
Backpressure: For Docker/K8s, ensure container/node memory limits exceed Redis maxmemory by 20–30% for overhead.

Troubleshooting

High misses, low evictions: Your cache may be under‑utilized—confirm the plugin is enabled, keys are being set, and TTLs aren’t too short.
Frequent evictions: Increase maxmemory (if you can), use allkeys-lfu, and consider lengthening TTLs for truly hot objects.
Memory keeps growing after traffic drops: Check fragmentation; run MEMORY PURGE or restart in a window.
Connection errors in ElastiCache: Verify Security Groups, subnet routing, and TLS/auth settings; increase timeouts slightly.
Shared Redis for multiple sites: Use unique WP_CACHE_KEY_SALT/prefix per site.

Appendix A — Baseline `redis.conf` (cache‑only)

save ""
appendonly no

# Adjust to your host/service
maxmemory 1gb
maxmemory-policy allkeys-lfu
maxmemory-samples 7

activedefrag yes
active-defrag-cycle-min 10
active-defrag-cycle-max 75

lazyfree-lazy-eviction yes
lazyfree-lazy-expire yes
lazyfree-lazy-server-del yes

tcp-keepalive 60
timeout 0

latency-monitor-threshold 100
loglevel notice

save ""

appendonly no

# Adjust to your host/service

maxmemory 1gb

maxmemory-policy allkeys-lfu

maxmemory-samples 7

activedefrag yes

active-defrag-cycle-min 10

active-defrag-cycle-max 75

lazyfree-lazy-eviction yes

lazyfree-lazy-expire yes

lazyfree-lazy-server-del yes

tcp-keepalive 60

timeout 0

latency-monitor-threshold 100

loglevel notice

Appendix B — Minimal `docker-compose.yml`

version: '3.9'
services:
  redis:
    image: redis:7-alpine
    command: ["redis-server", "/usr/local/etc/redis/redis.conf"]
    volumes:
      - ./redis.conf:/usr/local/etc/redis/redis.conf:ro
    healthcheck:
      test: ["CMD", "redis-cli", "PING"]
      interval: 10s
      timeout: 2s
      retries: 5

  wordpress:
    image: wordpress:php8.2-fpm
    depends_on:
      - redis
    environment:
      # DB_*, WP_*, etc.

version: '3.9'

services:

redis:

image: redis:7-alpine

command: ["redis-server", "/usr/local/etc/redis/redis.conf"]

volumes:

- ./redis.conf:/usr/local/etc/redis/redis.conf:ro

healthcheck:

test: ["CMD", "redis-cli", "PING"]

interval: 10s

timeout: 2s

retries: 5

wordpress:

image: wordpress:php8.2-fpm

depends_on:

- redis

environment:

# DB_*, WP_*, etc.

Appendix C — Example `wp-config.php` snippet

// Redis Object Cache (common settings)
define('WP_REDIS_CLIENT', 'phpredis');

// One of the following depending on your setup:
// Localhost TCP
// define('WP_REDIS_HOST', '127.0.0.1');
// define('WP_REDIS_PORT', 6379);

// Docker service name
// define('WP_REDIS_HOST', 'redis');
// define('WP_REDIS_PORT', 6379);

// ElastiCache (TLS optional)
// define('WP_REDIS_SCHEME', 'tls');
// define('WP_REDIS_HOST', 'my-redis.xxxxxx.use1.cache.amazonaws.com');
// define('WP_REDIS_PASSWORD', '...'); // if auth enabled

// Cache hygiene
define('WP_REDIS_MAXTTL', 86400);         // typical 1 day
define('WP_CACHE_KEY_SALT', 'example.com:');  // make unique per site
// Optional, if supported by your plugin version
define('WP_REDIS_PERSISTENT', true);

// Redis Object Cache (common settings)

define('WP_REDIS_CLIENT', 'phpredis');

// One of the following depending on your setup:

// Localhost TCP

// define('WP_REDIS_HOST', '127.0.0.1');

// define('WP_REDIS_PORT', 6379);

// Docker service name

// define('WP_REDIS_HOST', 'redis');

// define('WP_REDIS_PORT', 6379);

// ElastiCache (TLS optional)

// define('WP_REDIS_SCHEME', 'tls');

// define('WP_REDIS_HOST', 'my-redis.xxxxxx.use1.cache.amazonaws.com');

// define('WP_REDIS_PASSWORD', '...'); // if auth enabled

// Cache hygiene

define('WP_REDIS_MAXTTL', 86400); // typical 1 day

define('WP_CACHE_KEY_SALT', 'example.com:'); // make unique per site

// Optional, if supported by your plugin version

define('WP_REDIS_PERSISTENT', true);

Need a hand?

If you share your RAM/CPU budget, traffic profile, and whether you’re on localhost, Docker, or ElastiCache, we can recommend an initial maxmemory, TTL strategy, and eviction policy tailored to your site(s).
